Eagle Frame

Description :
The Eagle VTOL Frame is a premium vertical take-off and landing (VTOL) drone frame designed for maximum performance, durability, and flexibility. Constructed entirely from lightweight yet ultra-strong carbon fiber, the Eagle VTOL offers an ideal foundation for professional-grade UAV applications.

This frame includes high-efficiency propellers and a structurally optimized design, ensuring excellent aerodynamic performance and endurance. It provides a robust platform for custom integrations, allowing users the freedom to choose and install their own avionics, payloads, and ground control systems (GCS) as per mission-specific requirements.

Eagle Vtol Frame
1. Drone Body:
Material :- Carbon Fiber composite
Wing Span :-2700mm
Fuselage Height:- 640mm
Fuselage Length :- 1470mm
Payload Bay:- 200mm*150mm*150mm

2. Aerodynamical efficient control surface seamlessly integrated into the wings of our Fixed-Wing VTOL (Vertical Takeoff and Landing) model and conventional tail section .
3. Landing Gear : Sturdy legs or skids that provide stability during takeoff and landing.
4. Open Integration : Compatible with a wide range of avionics, flight controllers, and GCS options.
5. Optimized for Versatility : Suitable for mapping, surveillance, delivery, and industrial inspection applications.

Eagle VTOL :

Delivery Time: 2-3 weeks
